Module-Steering Column Control C5 (D3816E)
Harness-Family: Airbag
Color: NA
Gender: FEMALE
Part Number: HARD_WIRED
Part Description: Not Available
Connector No: D3816E
Option: Standard
Repair Kit Part Number: Not Available
Cavity Count:
| Pin | Circuit | Wire Color | Gauge/Size | Function | Option | ||
|---|---|---|---|---|---|---|---|
| 1 | R43 | BR | 20 | DRIVER SQUIB 1 LINE 2 | N/A | ||
| 2 | R45 | OR | 20 | DRIVER SQUIB 1 LINE 1 | N/A | ||
| 3 | R61 | VT | 20 | DRIVER SQUIB 2 LINE 2 | N/A | ||
| 4 | R63 | WT | 20 | DRIVER SQUIB 2 LINE 1 | N/A | ||
|
|||||||
