2002 Chrysler ProwlerFACTORY OEM SERVICE PROCEDURE

O2 Sensor Configuration

SENSOR CONFIGURATION

JR	4 CYLINDER	1/1	UPSTREAM
JR	4 CYLINDER	1/2	DOWNSTREAM
JR	2.7LV-6	1/1	REAR BANK UP
JR	2.7LV-6	1/2	REAR BANK DOWN
JR	2.7LV-6	2/1	FRONT BANK UP
JR	2.7LV-6	2/2	FRONT BANK DOWN
LH	V-6 ALL	1/1	RIGHT BANK UP
LH	V-6 ALL	1/2	RIGHT BANK DOWN
LH	V-6 ALL	2/1	LEFT BANK UP
LH	V-6 ALL	2/2	LEFT BANK DOWN
RSRG	ALL	1/1	UPSTREAM
RSRG	ALL	1/2	DOWNSTREAM
PL	ALL	1/1	UPSTREAM
PL	ALL	1/2	DOWNSTREAM
PR	3.5L	1/1	RIGHT BANK UP
PR	3.5L	1/2	RIGHT BANK DOWN
PR	3.5L	2/1	LEFT BANK UP
PR	3.5L	2/2	LEFT BANK DOWN
PT	ALL	1/1	UPSTREAM
PT	ALL	1/2	DOWNSTREAM

Fig 1: Identifying O2 Sensor Configuration

Courtesy of DAIMLERCHRYSLER CORP.
