1995 Chrysler LHSFACTORY OEM SERVICE PROCEDURE
Connector Identification
CONNECTOR IDENTIFICATION DIRECTORY
| Connector | Figure |
|---|---|
| ABS Relay | 8 |
| Brake Fluid Level Switch No. 1 | 9 |
| Brake Fluid Level Switch No. 2 | 10 |
| CCD Data Link | 11 |
| Controller Anti-Lock Brake (CAB) | 12 |
| Electronic Message Center | 13 |
| Mechanical Message Center | 14 |
| Pedal Travel Sensor | 15 |
| Pump/Motor (Harness End) | 16 |
| Pump/Motor Relay | 17 |
| Traction Control System Switch | 18 |
| Wheel Speed Sensors | 19 |
