Front Side Door Lock Cover Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedure Quarter Window Trim Finish Panel Replacement (Coupe) , or Quarter Window Trim Finish Panel Replacement (Convertible) |
|
| 1 | Front Side Door Latch Bolt [3x]
NOTE:
Support the front side door lock cover and front side door latch before removing the front side door latch bolts. Procedure Remove the front side door latch bolts. Front Side Door Latch Replacement |
| 2 | Front Side Door Lock Cover |
