2005 Chevrolet SSR AutomaticFACTORY OEM SERVICE PROCEDURE
Installation Procedure
WARNING: This page is about a different car, the 2005 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:
If the fuel injectors are being removed for the replacement of the fuel rail, it is not necessary to replace the O-rings on the fuel injector. Replace the O-rings only if they are damage.
- Apply a small amount of clean motor oil to the O-rings (8) and (9), before installing the new fuel injector.
- Install the fuel injector (7) in the fuel rail (2).
- Install the retaining clips for the fuel injector (6).
- Reconnect the electrical connector (50 for the fuel injector (7).
- Install the fuel rail assembly (2). Refer to Fuel Rail Assembly Replacement .
- Inspect for leaks:
- Turn the ignition switch ON for 2 seconds.
- Turn the ignition switch OFF for 10 seconds.
- Turn the ignition switch ON.
- Inspect for fuel leaks.
