2003 Chevrolet SSR BaseFACTORY OEM SERVICE PROCEDURE
Removal Procedure
- Open the hood.
- Cover and protect the following parts from broken glass:
- The upper dash pad
- The defroster outlets and A/C outlets
- The seats and carpeting
- Disconnect the antenna cable. Refer to Antenna Cable Replacement in Entertainment.
- Remove the windshield wiper arms. Refer to Wiper Arm Replacement in Wipers/Washer Systems.
- Remove the cowl air inlet grille panel. Refer to Air Inlet Grille Panel Replacement in Body Front End.
- Remove the windshield frame appliques. Refer to Applique Replacement - Windshield Frame in Exterior Trim.
- Remove the rearview mirror. Refer to Rearview Mirror Replacement .
IMPORTANT:
Before cutting out a stationary window, apply a double layer of masking tape around the perimeter of the painted surfaces and the interior trim.
CAUTION:
If broken glass falls into the defroster outlets, it can be blown into the passenger compartment and cause personal injury.
