1992 Cadillac Seville BaseFACTORY OEM SERVICE PROCEDURE

Pcm Code E096,Torque Converter Overstress: Action

PCM will set PCM Code E096. No service light or message is given.

PCM CODE E096 DATA

Gear Position	PRNDL ED71 CKT 773	PRNDL ED71 CKT 772	PRNDL 2 ED72 CKT 771	PRNDL 2 ED72 CKT 776
P	1	1	0	0
R	1	0	0	1
N	1	0	1	0
OD	0	0	1	1
3	0	0	0	0
2	0	1	0	1
1	0	1	1	0

Fig 1: PCM Code E096, Schematic, Torque Converter Overstress

Courtesy of GENERAL MOTORS CORP.
