2007 Buick Rainier AWD L6-4.2LFACTORY OEM SERVICE PROCEDURE
Refrigerant Pressure Sensor / Switch: Service and Repair
Air Conditioning (A/C) Refrigerant Pressure Sensor Replacement
Removal Procedure
1. Raise the vehicle. Refer to Vehicle Lifting.
2. Disconnect the electrical connector from the A/C refrigerant pressure sensor. The connector is accessible through the lower control arm.
3. Remove the A/C refrigerant pressure sensor from the compressor hose block.
4. Remove and discard the O-ring seal from the A/C refrigerant pressure sensor.
Installation Procedure
1. Install the new O-ring seal.
Notice: Refer to Fastener Notice.
2. Install the A/C refrigerant pressure sensor to the compressor hose block.
Tighten the A/C refrigerant pressure sensor to 4.8 N.m (42 lb in).
3. Connect the electrical connector to the A/C refrigerant pressure sensor.
4. Leak test the fittings of the component using J39400-A.
5. Lower the vehicle.
