1996 Buick Roadmaster BaseFACTORY OEM SERVICE PROCEDURE
Torque Specifications
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | ||
|---|---|---|---|
| Column Bracket-To-Instrument Panel Stud Nuts | 20 (27) | ||
| Column Bracket-To-Upper Support Bolts | 20 (27) | ||
| Flexible Coupling Nuts | 20 (27) | ||
| Intermediate Shaft-To-Steering Shaft Bolt | 35 (47) | ||
| Lower Intermediate Shaft-To-Steering Gear Box Bolt | 35 (47) | ||
| Steering Wheel Nut | 30 (41) | ||
| Steering Wheel Rotation Sensor | 40 (54) | ||
| Upper Intermediate Shaft-To-Steering Column Bolt | 40 (54) | ||
| INCH Lbs. (N.m) | |||
| Air Bag Module Screws | 25 (2.8) | ||
| Dimmer Switch Nut & Stud | 35 (4) | ||
| Ignition Switch Screw & Stud | 35 (4) | ||
| Lock Cylinder Screws | 22 (2.5) | ||
| Lock Housing Cover Screws | 80 (9) | ||
| Support-To-Jacket Screws | (1) 77 (8.8) | ||
| Turn Signal Switch Screws | 30 (3.4) | ||
|
|||
