2002 BMW 330xi AutomaticFACTORY OEM SERVICE PROCEDURE
Engine Performance: Application: Introduction: Introduction: Notes
2002 MODEL COVERAGE
| MODEL | BODY | ENGINE | FUEL SYSTEM | IGNITION SYSTEM |
|---|---|---|---|---|
| M-Coupe | E36 | 3.2L 6-Cyl. S54 | Bosch MS S54 | DIS |
| M-Roadster | E36 | 3.2L 6-Cyl. S54 | Bosch MS S54 | DIS |
| M3 | E46 | 3.2L 6-Cyl. S54 | Bosch MS S54 | DIS |
| M5 | E39 | 5.0L 8-Cyl. S62 | Siemens MS S52 | DIS |
| X5 | E53 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| X5 | E53 | 4.4L V8 M52 | Bosch Motronic 7.2 | DIS |
| X5 | E53 | 4.6L V8 M62 | Bosch Motronic 7.2 | DIS |
| Z3 | E36 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| Z3 | E36 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| Z8 | E52 | 5.0L V8 S62 | Siemens MS S52 | DIS |
| 325i | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 325Ci | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 325xi | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330i | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330Ci | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330xi | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 525i | E39 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 530i | E39 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 540i | E39 | 4.4L V8 M62 | Bosch Motronic 7.2 | DIS |
| 745i | E65 | 4.4L V8 N62 | Bosch Motronic 9.2 | DIS |
| 745Li | E66 | 4.4L V8 N62 | Bosch Motronic 9.2 | DIS |
2003 MODEL COVERAGE
| MODEL | BODY | ENGINE | FUEL SYSTEM | IGNITION SYSTEM |
|---|---|---|---|---|
| M3 | E46 | 3.2L 6-Cyl. S54 | Bosch MS S54 | DIS |
| M5 | E39 | 5.0L 8-Cyl. S62 | Siemens MS S52 | DIS |
| X5 | E53 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| X5 | E53 | 4.4L V8 M62 | Bosch Motronic 7.2 | DIS |
| X5 | E53 | 4.6L V8 M62 | Bosch Motronic 7.2 | DIS |
| Z4 | E85 | 2.5L 6-Cyl. M54 | Siemens MS 45 | DIS |
| Z4 | E85 | 3.0L 6-Cyl. M54 | Siemens MS 45 | DIS |
| Z8 | E52 | 5.0L V8 S62 | Siemens MS S52 | DIS |
| 325i | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 325Ci | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 325xi | E46 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330i | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330Ci | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 330xi | E46 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 525i | E39 | 2.5L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 530i | E39 | 3.0L 6-Cyl. M54 | Siemens MS 43 | DIS |
| 540i | E39 | 4.4L V8 M62 | Bosch Motronic 7.2 | DIS |
| 745i | E65 | 4.4L V8 N62 | Bosch Motronic ME9.2 | DIS |
| 745Li | E66 | 4.4L V8 N62 | Bosch Motronic ME9.2 | DIS |
| 760Li | E66 | 6.0L V12 N73 | Bosch Motronic ME 9.2.1 | DIS |
