Relays & Solenoids: Relays
For fuel pump relay, see FUEL DELIVERY under FUEL SYSTEM. For relay locations, see DME & FUEL PUMP RELAY LOCATION table. See Fig 1-Fig 30 .
| Application | Location | |
|---|---|---|
| X5 | ||
| DME Relay | Right Rear Corner Of Engine Compartment, Next To DME PCM | |
| Fuel Pump Relay | Behind Glovebox | |
| Z8 | ||
| DME Relay | Right Rear Corner Of Engine Compartment, Next To DME PCM | |
| Fuel Pump Relay | In Right Rear Of Storage Compartment | |
| 3-Series (Z3) | ||
| DME Relay | Right Rear Corner Of Engine Compartment, Next To DME PCM | |
| Fuel Pump Relay | Under Left Side Of Instrument Panel, Next To Kick Panel | |
| 3-Series (E46) | ||
| DME Relay | Left Rear Corner Of Engine Compartment, In Relay/PCM Box | |
| Fuel Pump Relay | Behind Glove Box | |
| 5-Series & 7-Series | ||
| DME Relay | Right Rear Corner Of Engine Compartment, Next To DME PCM | |
| Fuel Pump Relay | Right Side Of Trunk | |
