1994 Audi S4FACTORY OEM SERVICE PROCEDURE
Spark Test
WARNING:
During the test, DO NOT touch ignition coil mounting bracket or spark plugs. There is a danger of electrical shock.
- Remove screws from ignition coil mounting bracket (arrows). See Fig 1 . Remove spark plugs. Disconnect harness connectors from all 5 fuel injectors.
- Install spark plugs in the spark plug connectors (if necessary, use new spark plugs) and place on the cylinder head cover as shown in the illustration. See Fig 2
. Operate starter and check for spark at spark plugs.WARNING: During the test, DO NOT touch ignition coil mounting bracket or spark plugs. There is a danger of electrical shock.
- If there is weak or missing spark on one or more of the spark plugs, repeat test using other spark plugs.
- If spark is still unsatisfactory, see IGNITION SYSTEMS in SYSTEM & COMPONENT TESTING article.
