Passenger's Window Switch Test
Remove passenger's door panel. See DOOR PANEL under REMOVAL & INSTALLATION. Remove the screws and the passenger's switch assembly. See Fig 1 . Remove the five mounting screws. Remove the passenger's switch (A) from the panel (B). See Fig 2 . Check for continuity between the terminals in each switch position. See Fig 3 . See PASSENGER'S POWER WINDOW SWITCH table.
| Application & Window Switch Position | Continuity Between Terminals No. |
|---|---|
| UP | 1, 2, 3, 4, 5 & 6 |
| OFF | 1, 2, 3, 4 & 6 |
| DOWN | 1, 3, 4, 5 & 6 |
